Roco 42430 curved track, R20 1962 mm radius, 5° angle, 173 mm lengthfor model railroading at HO 1/87 scale.
2 Roco 42430 counter curves can be used in order to make a track parallel to your 10° switches and crossings.
Roco track profile is in code 83.
The Roco 42530 R20 curved track will allow you to make a parallel track using 2 copies with Roco 10° angle switches or crossings.
The Rocoline curved rail range consists of 6 different radii numbered R2 through R6 and R9:
R2: 358 mm radius Roco 42422 30° angle.
R3: 419.6 mm radius Roco 42423 30° angle.
R4: 481.2 mm radius Roco 42424 30° angle.
R5: Rayon 542.8 mm Roco 42425 30° angle.
R6: Rayon 604.4 mm Roco 42426 30° angle.
R9: Rayon 826.4 mm Roco 42427 15° angle.
R21/4: Small R2 curved rail of 358 mm radius Roco 42408 7.5° angle (for use with Roco 42432/42433 turnouts).
R31/4: Small R3 curved rail of 419.6 mm rod Roco 42409 7.5° angle.
R10: 888 mm radius Roco 42428 15° angle (for use with 15° angle turnouts to make a parallel track).
R20: 1962 mm radius Roco 42430 5° angle (for use with 10° angle turnouts to make a parallel track).
The RocoLine track system is a so-called "2 Rails"power system operating in direct current in both analog and digital modes.
Discover the RocoLine track, which is replicated with heavy-duty plastic sleepers that perfectly mimic railroad rails.
These rails, will perfectly equip your model train layout and allow the running of your trains at Ho 1/87 scale .
The connection of two RocoLine rails is done via the rail's joint bars.
Once connected,the junction between 2 rails is discrete.
To supply your tracks with analog, you can use the Roco rail reference 42421.
For digital operation, use the Roco connection cable reference 42613.
|Angle ( degrees )||5°|
|Scale||HO : 1/87|
|Radius ( in mm )||1962|
|Length ( in mm )||173|
